Seam Closing Machine (Duct Zipper) SBHF Quick Detail: Duct Zipper is a convenient sewing equipment. With just a gentle push, the two boards will be securely locked together. Description: Dual Zipper is mainly used for the production of square tubes. The equipment requires manual operation and is more suitable for small batch and scattered air duct production. The equipment is driven by a motor, making it convenient and labor-saving to sew. Parameter:

Technical Data
Thickness		0.5-1mm
Min.Duct diameter		100/100mm
Max.Feeding speed		15m/min
Support Height		700mm
Support Length		1500mm
Number of Support arms		2×3
Working Height		800mm
Dimension	Length	5350mm
	Width	1000mm
Max.Power		3kW
Max.Weight		710Kg
Voltage		380V/50HZ/3PH
